Compact water chiller CW-5200 is applicable to cool up to 150W CO2 laser cutting and engraving machine. It is produced by TEYU S&A Chiller, a professional China-based water chiller manufacturer and supplier with 22-year experience.
Hot-selling industrial water chiller CW-5200 features the cooling capacity of 1430W and the temperature stability of ±0.3℃ in addition to 6L tank capacity. What makes air cooled chiller CW-5200 outperforms other chiller brands is that it has intelligent temperature controller which can display water temperature & room temperature and realize multiple alarm functions, such as compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high/low temperature alarm so that the water chiller can be well protected.
Compact water chiller CW-5200 is equipped with water level gauge, so that users no longer have to worry about if they are adding too much water inside. The suitable water level is within the green indicator of the water level gauge.
Hot-selling industrial water chiller CW-5200 conforms to the standard of UL, CE, RoHS, REACH and ISO, so users in different countries can rest assured when using air cooled industrial chiller CW-5200. Besides, TEYU S&A Chiller offers 2-year warranty on all the chillers it produces.
It is suggested to use purified water or clean distilled water as the circulating water to reduce the possible clogging inside the circulating waterway.
Detailed introduction of compact water chiller CW-5200:
https://www.teyuchiller.com/industrial-chiller-cw5200-hot-selling-water-chiller-unit
Specification:
Voltage:110V-240V; Frequency: 50/60Hz; Refrigerant: R-134a/R-410a
Pump power: 0.03KW/0.09KW; Tank capacity:6L
Max. pump pressure: 1.2bar-2.5bar; Max. pump flow: 13L/min- 15L/min
N.W: 25Kg; G.W: 28Kg;
Dimension: 58*29*47cm (L X W X H); Packing dimension: 65*36*51cm (L X W X H)
About TEYU Brand
TEYU S&A Chiller was founded in 2002. After 22 years of developing and producing industrial water chillers, the headquarters covers an area of 30,000 square meters and has over 500 employees.
Why choose TEYU S&A Chiller
Product Advantages:
- With 11 patent certificates, ISO, CE, RoHS and REACH compliant; Conforms to air transport requirements; 2 years warranty
2.±0.1℃ high precision temperature control, stable cooling performance, support ModBus-485 communication;
- Establish logistic warehouses at USAand Europe;
Manufacturing Advantages:
- Independent R&D on sheet metal, evaporator, condenser and cores parts of chiller;
- Annual output 160,000 units, product exports rate above 60%；
- Standard bulk production, standard parts rate up to 80%；
- With excellent laboratory testing system, simulates actual working environment for chiller.
