Closed circuit water chiller CWFL-3000 is specially designed for cooling 3000W fiber laser of fiber laser metal cutting machine. It is produced by TEYU S&A Chiller, a professional China-based chiller manufacturer and supplier with 22-year experience.
Dual circuit water chiller CWFL-3000 is characterized by the large cooling capacity and the ±0.5℃ temperature control accuracy. With dual temperature control system, air cooled dual temperature water chiller CWFL-3000 can cool the fiber laser device and the optics/QBH connector at the same time, which is space saving and cost saving.
Closed circuit water chiller CWFL-3000 has two temperature control modes as intelligent & constant temperature control mode. Under constant temperature control mode, the water temperature can be set as a fixed value as required. Under intelligent temperature control mode, the water temperature will be adjust itself according to the change of the ambient temperature, which greatly avoid the condensed water.
Dual circuit water chiller CWFL-3000 has got the approval from CE, REACH, RoHS and ISO. It can be applied to cool fiber lasers of different brands, such as IPG, Raycus, SPI, Trumpf, nLight and so on.
Dual circuit water chiller CWFL-3000 video:
Specification:
Voltage:220/380V; Frequency: 50/60Hz;
Pump power: 0.75kW/1kW; Tank capacity:22L
Max. pump pressure: 5bar/5.9bar; Rated flow: 2L/min+>30L/min
N.W: 93Kg; G.W: 109Kg;
Dimension: 77*55*103cm (L X W X H); Packing dimension: 78*65*117cm (L X W X H)
About TEYU Brand
TEYU S&A Chiller was founded in 2002. After 22 years of developing and producing industrial water chillers, the headquarters covers an area of 30,000 square meters and has over 500 employees.
Why choose TEYU S&A Chiller
Product Advantages:
- With 11 patent certificates, ISO, CE, RoHS and REACH compliant; Conforms to air transport requirements; 2 years warranty
2.±0.1℃ high precision temperature control, stable cooling performance, support ModBus-485 communication;
- Establish logistic warehouses at USAand Europe;
Manufacturing Advantages:
- Independent R&D on sheet metal, evaporator, condenser and cores parts of chiller;
- Annual output 160,000 units, product exports rate above 60%;
- Standard bulk production, standard parts rate up to 80%;
- With excellent laboratory testing system, simulates actual working environment for chiller.
